The ABE-100W Wireless Dual Beam for the Paradox M-25 series is a high-performance, battery-powered perimeter detection solution designed for secure outdoor environments. Featuring a wireless transmitter and receiver pair, this dual-beam system offers flexibility, long battery life, and reliable detection for residential, commercial, and industrial applications.
Key Features:
- Supports up to 2 x ER26500 lithium batteries per unit (transmitter & receiver).
- Supplied with 1 battery per beam; an additional battery is recommended for high-traffic areas.
- High-Security Compatibility:
- Includes 1 x ZX-22 wireless transmitter.
- A second transmitter can be installed for high-security zones (sold separately).
- Frequency Selection: 4 independent channels to avoid signal interference between multiple beams.
- Selectable Response Times: Adjustable response times: 50 ms, 100 ms, 300 ms, 700 ms, offering flexibility based on environment and security requirements.
- Easy Alignment with LED Indicators:
- Green (GOOD): Perfect alignment
- Blue (LEVEL): Intermediate alignment
- Red (ALARM): Misalignment or beam interruption
- Adjustable Transmitter Power Levels: Choose from four TX output settings to optimize range and battery life:
- XL = 100% (maximum range)
- L = 70%
- M = 40%
- S = 20% (extends battery life)
- Robust Build and Tamper Protection: Front lid and wall tamper switches for enhanced security. Wall tamper can be disabled if not required
- Flexible Installation Options: Supports horizontal and vertical alignment adjustments for precise beam placement.
